| Phase current, max | 60A |
| PWM frequency | 8–20 kHz |
| Maximum Controller output frequency | 500 Hz |
| Electrical isolation to heatsink | 500 VAC |
| Storage ambient temperature | -40°C to 75°C |
| Operating ambient temperature | -20°C to 50°C |
| Thermal cutback | Controller linearly reduces maximum current limit with an internal heatsink temperature from 85°C to 95°C, complete cutoff occurs above 95°C |
| Package environmental rating | IP67 (excluding electrical connections) |
| Speed regulation (range) | +/- 5% at top speed |
| Minimum motor phase to phase inductance | 20 μH |
| Motor control scheme | Sinusoidal field oriented (FOC) |
| Motors supported | PMAC and BLDC |
| Input Power | 18V to 85V |
Can be attached to additional heat sinks
to significantly increase performance.
Configurable throttle, brake cut-off,
and regeneration options.
Ensures low ripple current and silent
motor operation.
Compatible with analog voltage models or BMS communication-based battery management systems.t
Enhances efficiency and ensures
tsmooth motor operation.
Supports sensorless or Hall commutation with automatic switching.
CANOpen.
Supports multiple sensor configurations.
Single pulse and quadrature pedal
tor wheel speed inputs.
Operate over a nominal battery voltage range.
Communication Protocol
| PROTOCOL | CONFIGURATION |
|---|---|
| CANOpen | Standard |
| CANOpen with BLE | Standard |
| TTL-232 with RS-485 | Optional |
| TTL-232 with TTL-232 | Optional |
| TTL-232 with BLE | Optional |
$650.00
